L140-30F 60TX11 Quantity of (4) 140°F Auto-Cycle Thermostat

Description

This is for 4 each of the Auto Cycle Thermostat

L140-3OD 312790 140° Single Pole 60TX11

• Size: 1 1/2″ C 2″ Oval with 1 5/8″ on Center Mounting Holes.
• 1/4″ Quick Connect Terminals and Drop through a hole into the air stream 3/8″.

Incorrect replacements could be a hazard!!!
Limit opens on rise of temperature. This unit with a (-3) or larger Differential are usually used in heaters and furnaces.

60TX 11 312790 L140-30 Open Disc
auto reset control from Therm-O-Disc® offers proven reliability in a compact, versatile, cost-effective design. The snap action of the bimetal disc provides high-speed contact separation resulting in excellent life cycle characteristics at electrical loads up to 25 amps at 240 VAC

60TX has electrical clearances of 1/4-inch through air and 3/8-inch over surface which may be required for some heating and air conditioning applications. Overall physical dimensions as the same as the 60T.

76S Series open coil heaters

call us for exact replacement

L140-30
L140-3OD
