S-5053 5kw 480v 3ph with 2″ N.P.T. Steel Screw Plug – Silver Brazed

Description

Steel Sheath Immersion Element
5kw 480v 3PH 2″ NPT Steeel Screw Plug

S-5053, S 5053, 351F-1009-034

For Oil – 22 Watts per square inch
B dim.: 31″ | C dim.: 29″
with 3/8″ ID SS Thermowell
Non-Regulated
General Enclosure

• Standard temperature range is 60°-250°F.
• For temperature range of 30°-110°F: add the suffix T1
• For temperature range of 200°-550°F: add the suffix T5
• For stainless steel header instead of brass header: add the suffix SSN. Consult factory.
• Regulated models require a magnetic contactor for the following conditions:
  • Single phase ampere rating over 30 amps
  • All 208 and 240 volt, 3 phase applications
  • All 480V, single and three phase applications.
• 208V models not shown are available upon request. Consult factory.
• 240V units may be derated for 208V usage with a 25% reduction in wattage.
