DCC-3043 Copper Sheath Immersion Element 3kw 240v 3ph 2 1/2″ N.P.T. Brass Screw Plug – Silver Brazed

Description

For Water – 60 Watts per square inch
With 3/8″ ID Copper Thermowell
Non-Regulated
General Purpose Enclosure

• Standard temperature range is 60°F-250°F.
• For temperature range of 30°F-110°F: add the suffix T1
• For temperature range of 200°F-550°F: add the suffix T5
• For stainless steel header instead of brass header: add the suffix SSN. Consult factory.
• Regulated models require a magnetic contactor for the following conditions:
  • Single phase ampere rating over 30 amps.
  • All 208 and 240 volt, 3 phase applications.
  • All 480V, single and 3 phase applications.
• 208V models not shown are available upon request. Consult factroy.
• 240V units may be derated for 208V usage with a 25% reduction in wattage.
