Description
Eichenauer’s UL listed flanged immersion heater can be used as replacement parts for boilers, steam generators, sterilizers, autoclaves, etc.
***PLEASE NOTE: 6 MONTH WARRANTY FROM PURCHASE DATE FOR ALL FLANGED IMMERSION HEATERS****
- Eichenauer 300447K Gasket 52322 (1Included) 5 pack 52322
UL Designation: 950-30-11
| FLANGE | 4½ sq |
|---|---|
| VOLTAGE | 480v |
| KW | 30 |
| PHASE | 3 |
| SHEATH | SS |
| NO. OF ELEMENTS | 6 |
| TERMINAL PINS | # 10-32 |
| IMMER. LENGTH | 16.25 |
| WATT DENSITY | 121 W/in² |
| ORDER NUMBER | 51A-1004-10 |
Flange
Thickness: 0.375
Mounting: 6 x 0.375 holes on a 3.8125 Dia B.C.
These are commonly used as replacements for Sussman, Electrosteam and many other boilers.
Steris / Chromalox series CHS Series 30, CHS 30AS (uses 1 heater total 1×30)
APPLICATIONS:
- Process Steam
- Air Humidification
- Dry Cleaning
- Food Service
- Laboratories
- Breweries
- Process Heating
- Shrink Wrap Labels
Always consult your owners/parts manual for the correct heating element for your Steam Boiler. We are not responsible for non compatibility.
NOT OEM
