Description
Eichenauer’s UL listed flanged immersion heater can be used as replacement parts for boilers, steam generators, sterilizers, autoclaves, etc.
***PLEASE NOTE: 6 MONTH WARRANTY FROM PURCHASE DATE FOR ALL FLANGED IMMERSION HEATERS****
- Eichenauer 300556H Gasket 52587 (1 Included)
UL Designation: 965-30-11
| FLANGE | 6 rnd |
|---|---|
| VOLTAGE | 480 |
| KW | 25 |
| PHASE | 3 |
| SHEATH | SS |
| NO. OF ELEMENTS | 3 |
| TERMINAL PINS | # 10-32 |
| IMMER. LENGTH | 36 |
| WATT DENSITY | 88 W/in² |
| ORDER NUMBER | 51A-1014-02 |
Flange
Thickness: 0.75
Mounting: 4 x 0.75 holes on a 4.75 Dia B.C.
These are commonly used as replacements for Sussman, Electrosteam and many other boilers.
Electro-Steam / series LB LB-100 (uses 4 heaters total 4×25)
Steris / Chromalox series CES Series 60 CH07 (uses 2 heaters total 2×30)
Electro-Steam / series LB LB-80 (uses 3 heaters total 3×25)
Electro-Steam / series LB LB-50 (uses 2 heaters total 2×25)
Steris P-764319-444, P764319444
Electro-Steam 0010126
APPLICATIONS:
- Process Steam
- Air Humidification
- Dry Cleaning
- Food Service
- Laboratories
- Breweries
- Process Heating
- Shrink Wrap Labels
Always consult your owners/parts manual for the correct heating element for your Steam Boiler. We are not responsible for non compatibility.
NOT OEM
